DAB EUROINOX40/80M Multistage Stainless Pump

0 Comments
DAB EUROINOX40/80M Multistage Stainless Pump

$725.00

SKU: DAB-EUROINOX40/80M Categories: , ,

Description

DAB EUROINOX 40/80M Multistage Stainless Steel  Pump

Euroinox Stainless Steel Self Priming Horizontal Multistage Pumps. Stainless steel pump body for bacteria and corrosion resistance. Brass non return valve and fittings for strength and durability. Replaceable TEFC motor with air gap to stop seal failure water entry.  2 year pump parts & labour warranty. DAB Pumps are made in Italy.

Note: EUROINOX pumps are AS/NZS4020 approved for drinking water.

Motor / power: 1000W
Volt:  240V
Horsepower: 1.36hp
Head: 59m
Max Flow Rate: 80lt/min
Taps: 12
Nominal Pressure: 303kPa
Maximum Pressure: 579kPa
Warranty on pump: 2 Year
Body: Cast Iron & Stainless Steel

dab-euroinox-series

euroinox40-80



For Technical Specifications, please click here.

For spare parts and exploded diagram, please click here, here, here, or here.

For Installation Manual, please click here.

Additional information

Product Type

Horizontal Multistage Pump

Brand

DAB Pumps

Suitable For

Clean Water

Bar

5.9 Bar

Approval

Approved for Drinking Water

Flow Range Category

b. 100 – 199 L/min

Flow Rate (LT/min)

120LT/min

Hp

1.36 Hp

kPa

598 kPa

Kilo Watts

1 kW

Head Range Category

b. 40 – 59 m

Head (max)

59m

Port Size Inlet

1" BSPF inlet

Port Size Outlet

1" BSPF outlet

Powered

Electric

Warranty

24 Months

Volts

240 V

Pack Weight

15.10 KG
