Grundfos CMBE 5-62 Booster Pump
Sale!

$2,688.11 $2,250.00

SKU: CMBE 5-62 Categories: , ,

Description

Grundfos CMBE 5-62 Booster Pump

The Grundfos CME Booster is a compact booster system for water supply in domestic applications. The integrated speed controller enables the CME Booster to keep constant pressure in the pipe system. A pressure sensor monitoring changes in the water consumption will signal to the speed controller to change the motor speed to adapt performance to the new state. The CME Booster is very easy to install. When the pipework has been installed, it is all a matter of plugging the unit into a socket, and the system is operational. The CME Booster consists of:

  • CME pump with integrated frequency converter
  • 5-way valve
  • expansion tank
  • pressure gauge
  • manometer

Features

  • Constant pressure, integrated speed control
  • Compact
  • Robust, stainless steel
  • Easy installation
  • Dry run protection

Thermal protection CME Booster pumps require no external motor protection. The MGE motor incorporates thermal protection against slow overloading and blocking (IEC 34.11: TP
211).

Product name CMBE 5-62 I-U-C-A-D-B
Product No 98374712
EAN number 5711493909521

Technical
Pump speed on which pump data are based 3868 rpm
Rated flow 5.6 m³/h
Rated head 44.2 m
Impellers 4
Primary shaft seal AVBE
Approvals and markings CE
Curve tolerance ISO9906:2012 3B
Model A
Start pressure Integrated Frequency converter

Materials
Pump housing Stainless steel
Pump housing DIN W.-Nr. 1.4301
Pump housing AISI 304
Impeller Stainless steel
Impeller DIN W.-Nr. 1.4301
Impeller AISI 304
Rubber EPDM

Installation
Maximum ambient temperature 55 °C
Flange standard WHITWORTH THREAD RP
Pump inlet Rp 1 1/4
Pump outlet Rp 1

Liquid
Pumped liquid Water
Liquid temperature range 0 .. 60 °C
Selected liquid temperature 20 °C
Density at selected liquid temperature 998.2 kg/m³

Electrical data
Rated power – P2 1.5 kW
Mains frequency 50 Hz
Rated voltage 1 x 200-240 V
Maximum current consumption 9.10-7.60 A
p max system 10 bar
Rated speed 360-4000 rpm
Enclosure class (IEC 34-5) IP55
Insulation class (IEC 85) F
Type of cable plug AU
Mains cable 1.5 m

Tank
Tank volume 2 l

Others
Net weight 19.3 kg
Gross weight 29.3 kg
Config. file no 98499013
